Triumph Tiger 800 XCA 2018 – OTR Price: £12,700.00
With the exhilarating all-new top spec Tiger 800 XCA your adventure literally starts here with a bike that’s now as great off road as it always was on.
Colour Options
Korosi Red
Seat height 840 – 860 mm
- Thrilling new generation 800cc engine providing more power and torque low down
- Lower ratio 1st gear improving acceleration and off-road traction
- Lighter, freer-flowing exhaust
- 5 Riding Modes: New Off-Road Pro, Road, Rain, Off-Road and Sport
- Full colour 5″ TFT angle adjustable display instruments
- Ergonomic Switchcubes and 5-way Joystick
- LED Daytime Running Light DRL set-up
- 5 riding modes: Off road pro, road, rain, off road and sport
- Brembo premium front brakes
- Premium Adjustable WP front and rear suspension
- 5 position screen and aero deflectors
- Updated Cruise Control
- LED self-cancelling indicators
- Laced wheels including 21” front
- Bridgestone Battlewing tyres
- Switchable ABS and Traction Control
- Engine Protection Bars
- Aluminium sump guard
- Aluminium radiator guard
- Tailored ergonomics – adjustable seat height, handlebar position, brake and clutch levers
- Comfort rider and pilion seats
- On Board computer
- 12V & USB Power Sockets
- Immobiliser
- Heated Grips
- Hand Guards
Additional to Tiger 800 XCX
- 6 riding modes: Off-road Pro, Road, Rain, Off-road, Sport and Rider programmable
- Ergonomically backlit switchcubes and 5 way joystick
- Heated rider and pilion seats
- All LED lighting including headlight, indicators and taillight
- LED auxiliary lighting
- 6 screen styles
- Additional 3 x TFT styles
- Centre Stand
- CNC Machined Footrests
The supremely off-road focused Tiger 800 XCA is equipped with switchable traction control, switchable ABS, six riding modes including new ‘Off-Road Pro’, and a new generation 95PS 800cc Triple engine with a lower ratio first gear for a seamless flow of torque lower-down and even better acceleration.
Standard equipment includes heated rider and passenger seats, heated grips, LED fog lamps, and auxiliary sockets that can power everything you need; from heated clothing to GPS systems. Triumph switchable traction control and a responsive ride-by-wire throttle set a new standard in off-road adventuring, while an improved riding position lets you make the most of the trademark Triumph agile handling. Add a 21” front wheel for true off-road performance and a high-level front mudguard and you have everything you need for a thrilling all-road experience.
Adventure riding has never been so good.
| Max Power EC | 95 PS/ 94 bhp (70 kW) @ 9,500 rpm |
|---|---|
| Max Torque EC | 79Nm @ 8,050rpm |
| Brakes Front | Twin 305 mm floating discs, Brembo 2piston sliding calipers, Switchable ABS |
| Brakes Rear | Single 255 mm disc, Nissin single piston sliding caliper, Switchable ABS |
| Front Suspension | WP 43 mm upside down forks, with adjustable rebound and compression damping, 220 mm travel |
| Rear Suspension | WP monoshock with remote oil reservoir, hydraulically adjustable preload, 215 mm rear wheel travel |
Engine and Transmission
| Type | Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder |
|---|---|
| Capacity | 800 cc |
| Compression | 11.3:1 |
| Max Power EC | 95 PS/ 94 bhp (70 kW) @ 9,500 rpm |
| Max Torque EC | 79Nm @ 8,050rpm |
| System | Multipoint sequential electronic fuel injection |
| Exhaust | Stainless steel 3 into 1 header system, side mounted stainless steel silencer |
| Final drive | O-ring chain |
| Clutch | Wet, multi-plate |
| Gearbox | 6 speed |
Chassis
| Frame | Tubular steel trellis frame |
|---|---|
| Swingarm | Twinsided, cast aluminium alloy |
| Front Wheels | Spoked, 21 x 2.15 in |
| Rear Wheels | Spoked, 17 x 4.25 in |
| Front Tyres | 90/9021 |
| Rear Tyres | 150/70 R17 |
| Front Suspension | WP 43 mm upside down forks, with adjustable rebound and compression damping, 220 mm travel |
| Rear Suspension | WP monoshock with remote oil reservoir, hydraulically adjustable preload, 215 mm rear wheel travel |
| Brakes Front | Twin 305 mm floating discs, Brembo 2piston sliding calipers, Switchable ABS |
| Brakes Rear | Single 255 mm disc, Nissin single piston sliding caliper, Switchable ABS |
| Instrument Display and Functions | TFT multifunctional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and six rider modes (Rain/Road/Off-road/Off-Road Pro/Sport/Rider-Customisable). |
DIMENSIONS AND WEIGHTS
| Width Handlebars | 805 mm |
|---|---|
| Height Without Mirror | 1,390 mm |
| Seat Height | 840 – 860 mm |
| Wheelbase | 1,545 mm |
| Rake | 23.4 º |
| Trail | 93.5 mm |
| Dry Weight | 208 Kg |
| Tank Capacity | 19 L |
FUEL CONSUMPTION
| Fuel Consumption ** | 4.7 l/100 km (60.6 MPG) |
|---|---|
| CO2 figures ** | EURO 4 Standard: 107 g/km. **CO2 and fuel consumption are measured according to regulation 168/2013/EC. Figures on fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results. |
